How to use Elenker Heavy Duty Rollator Walker with Seat?

The ELENKER Heavy Duty Rollator Walker is a robust mobility aid designed to support individuals weighing up to 500 lbs. It features an extra-wide padded seat and backrest for enhanced comfort during use. The frame is fully adjustable, accommodating users of varying heights, and the 10-inch wheels ensure smooth navigation across different terrains. Additional conveniences include an under-seat basket, cane holder, and cup holder, allowing users to keep essential items within reach.

ELENKER 9219 Heavy Duty Rollator

Parts of Elenker Heavy Duty Rollator Walker with Seat

1 Handgrip
2 Backrest
3 Cup Holder
4 Under-seat Basket
5 Front Wheel
6 Handbrake
7 Padded Seat
8 Cane Holder
9 Rear Wheel

The Curb Climber

Use it to overcome obstacles such as curbs and thresholds.

How to use handbrakes

1. Squeeze to slow

2. Push down to lock the rear wheels

How to Fold Elenker Heavy Duty Rollator Walker

Pull up the under-seat bracket to fold the walker.

How to adjust brakes

Brake Issue: The brake cannot engage rear wheel when squeezing handbrake
(fig A).

Adjust Rear Brake Position

Tools: Plier or 10mm wrench (fig 1).
Use plier(or 10mm wrench) to turn M6 nut counter-clockwise(fig 2-3). And brake will be closer to wheel(fig 4). Then squeeze handbrake, if it doesn't work, repeat the steps until rear brake can engage wheel.
